A square 500 × 500 mm cabinet makes the wall ratio equal to columns ÷ rows. For an exact 16:9 canvas you need 144 cabinets at 16 × 9 (8.0 × 4.5 m). This guide gives the grid options, the five-step calculation, resolution per pitch, and power, weight and case counts for a 144-cabinet wall.
